1W-5W Animated laser light
• 5000mW full-color laser output
• DMX + ILDA + app control
• 128 built-in animation effects
24/7 Support
1095 Warranty
Lifetime Servic
- Parameters
- video
- Manual
| Item | Specification | Item | Specification |
|---|---|---|---|
| Rated Voltage | AC110V / AC230V ±10% | Rated Frequency | 50–60Hz |
| Rated Power | 90W | Laser Power | RGB 5000mW |
| Laser Source | Semiconductor laser | Laser Modulation | Analog signal |
| Laser Color | Full color | Laser Patterns | 128 animation effects |
| Wavelength | R:638nm / G:530nm / B:450nm | Output Power | R:1000mW / G:1000mW / B:3000mW |
| Scanning System | 15Kpps galvanometer | Scan Angle | ±25° |
| Channels | 12 / 19 CH | Control Signals | DMX512, ILDA, Sound, Auto |
| Control Mode | DMX, Auto, Sound, Master/Slave, App (Bluetooth) | Cooling | Fan cooling system |
| Laser Class | Class 3R | Interface | 3-pin DMX, power I/O, ILDA I/O |
| Product Size | 16 × 18.5 × 14.5 cm | Net Weight | 2.15 kg |
| Certification | CE / FCC / ROHS | — | — |
