Power: AC100-240V, 50/60Hz
-
Total Power: 600W
-
Bulb model: 380W beam
-
The light flux is 7,950 LM and the color temperature can reach 8,500 K
-
Electrical ballast
-
Control: DMX512/WDMX/self-propelled
-
Channel: a 16-channel display with a nice bitmap, four flip-flops and a 180-degree display
-
Color disc: a color disc, each color disc by 14 color composition + white, 6 colorful colors, rainbow effect
-
Adjustable rotation speed, two-way flow and rainbow effect. Pattern disc: fixed pattern disc,
-
10 fixed patterns + 4 glass images (14 pattern effects + white light)
-
PRISMS: 48 honeycomb prisms, 12 prisms, double prisms can be stacked bidirectional independent rotation bidirectional rotation, rotation speed adjustable.
-
Focus: linear focus, from near to far. With atomization function, atomization speed is adjustable.
-
0-100% mechanical dimming, supports mechanical stroboscopic and speed-adjustable stroboscopic effects, and supports stroboscopic macro function. The mechanical stroboscopic value is 1-12f. P. S.
-
A color disc, each color disc by 14 color sheet composition + white, rotation speed is adjustable, two-way flow effect and Rainbow Effect °
-
A photoelectric reset system is used to automatically retrieve and reset the color disc after accidental misoperation
-
Level 540 ° , 8 bit/16 bit fine tuning
-
270 ° vertical, 8 bit/16 bit fine tuning
-
It has horizontal and vertical fine-grained automatic error correction.
-
Overheat protection
-
IP protection: IP20
-
Liquid crystal display.
-
Dimensions: 280 × 240 × 530mm
-
NET weight: 12Kg
-
Box Size: 56 * 38 * 44cm
- Gross weight: 15Kg
