- Rated voltage: AC110-220V
- Shaking head laser+LED aperture
- Rated frequency: 50-60Hz
- Rated power: 300W
- Laser color: RGB full-color
- Laser power: RGB 10W/RGB 5W
- Laser light source: R3w/638nm G3w/525nm B4w/447nm/（5W-R1，G1，B3）
- Laser pattern: 256 laser animation patterns
- Modulation signal: TTL modulation (analog modulation)
- Scanning system: galvanometer scanning 30KPPS
- Scanning angle: plus or minus 20 degrees
- Stepper motor: 2 two-phase 57 motors
- Horizontal: 540 degrees Vertical: 270 degrees
- LED dyeing configuration: Three layer wheat jazz light strip
- Control method: DMX512， Voice control, self-propelled, computer ILDA interface, Ethernet Art Net,
- Control channel: 20/25 channels
- DMX special effects: single pattern mode, with functions such as pen breakage, flicker, rotation, movement, scrolling, segmentation, gradient drawing, color change, and resizing.
- Function: Can be controlled by laser software such as pangolin QSFB3/FB4 or Phoenix.
- The ILDA control adopts an automatic electronic transfer switch, which has scanning system error protection and laser shutdown protection.
- Instructions for use: The ambient temperature should be controlled between 0~35 ℃. A dry and dust-free environment can reduce laser power attenuation and extend the lifespan of the lamp
- Suitable venues: nightclubs, bars, nightclubs, concerts, advertising promotions, etc
- Cooling system: fan forced cooling of Shaking head laser+LED dye light
- Bare lamp size: 29 * 24 * 45cm
- Net weight: 10kg
- Packaging size: 50 * 35 * 37cm
- Gross weight: 12kg
